LGA 1150 vs 1151 vs 1200

We all know that many components go into the making of a full-fledged computing system. These components ultimately determine the system’s overall functionality. One such crucial component of every system is the motherboard. While the CPU is considered the brains of every computer, the motherboard/processor is recognized as the heart.  Every operation directly or indirectly involved with the PC’s functioning is carried out by the motherboard, also known as the mainboard, system board, baseboard, or logic board. The motherboard is located inside of your computer on a system tray.

A motherboard comprises multiple components that are essential for the smooth and efficient functioning of your system. The motherboard is the route through which various computer peripherals interact. One such crucial ingredient of your system’s processor is its CPU socket. The CPU socket consists of pins that provide either mechanical or electrical connections between your system’s microprocessor and the circuit board.

The CPU socket facilities CPU access while preventing damage to your system every time you insert or remove a computer peripheral. These CPU sockets tend to be different for Intel core processors and AMD CPUs. With newer introductions each year, it becomes essential for you to keep up with the evolving technology. The processor is the most crucial component of your PC. Whether you use your PC for gaming, graphics design, video editing, or other “heavy” operations. You need to invest in the right high-performance processor.

Intel’s 1150, 1151, and 1200 CPU sockets are currently the market’s hot topic. These CPU sockets have done exceptionally well when it comes to improving the motherboard’s overall functionality. Nearly every new CPU comes with its socket.  However, if you already have a motherboard, there are limited CPU options available at your disposal and vice versa. Therefore, to make things easier, we have listed all the specifications and differences between the 1150, 1151 and 1200  Intel Sockets from one another.

Note:  Having already used pins and cartridges for the CPUs, Intel has moved on to a pin mounting system called the Land Grid Array (LGA). This means that these CPUs use electrical contact pads on the rear with the pins already inside the CPU socket on the motherboard.

LGA 1150 Review

LGA 1150 Review

One of the most popular types of processors currently available for purchase is Intel’s LGA 1150. The LGA 1150, generally referred to as the H3 socket, was launched post the release of Intel’s LGA 1155 H2 socket. Built on the  Haswell architecture, these CPU sockets comprises 1150 pins that enable communication between the motherboard and the processor, hence the name. The LGA 1150 is fully compatible with all Intel processors and also supports both Haswell and Broadwell processors.

A motherboard equipped with the LGA 1150 CPU socket can fully support HDMI, VGA, and DVI connections and is compatible with the DDR3 RAM. The CPU cooling is backward compatible, meaning it offers full compatibility with the older 1156 and 1155 LGA CPU sockets. Unfortunately, these LGA 1150 CPU sockets are now outdated since they do not support DDR4 RAM. The LGA1150 is compatible with Intel B85, H81, H87, Q85, Q87, Z87, H97, Z97 desktop chipsets and the C226 server chipsets. However, it is NOT compatible with the Skylake processor.

LGA 1151 Review

LGA 1151 Review

Also built on Haswell’s microarchitecture, the LGA 1151 CPU socket was launched as the successor to the 1150 CPU socket in 2015. Referred to as the H4 socket, the LGA 1151 is the second revision for Coffee Lake CPUs. The LGA 1151 has 1151 pins on the bottom of the socket that facilitate communication between the processor and the motherboard. 1151 is currently the desktop socket and is based on the 7th gen, 8th gen and 9th generations of Intel Chipsets. This CPU socket uses the right orientation with the heatsink fastening holes placed in a square formation. The LGA 1151 supports the following chipsets.

  • H110
  • B150
  • Q170
  • Z170
  • Z370

The LGA 1151 CPU sockets allow for the same cooling as the older 1150 and 1151 H2 sockets and can carry HDMI, DVI, DisplayPort, and VGI connections. The 1151 currently has two versions available which aren’t compatible with each other. The major downside of the 1151 LGA Intel CPU socket is that it does NOT allow overlocking, unlike its earlier models. The Intel LGA 1151 is NOT backward compatible.

LGA 1200 Review

LGA 1200 Review

The LGA 1200 is a modified version of the 1151 H4 socket and is compatible with the Comet Lake and Rocket Lake Desktop CPUs. The LGA 1200 was introduced as a potential replacement to the 1151 CPU Socket. 1200 comprises 1200 pins mounted at the rear of the motherboard that facilitates communication between the motherboard and the processor.

It comes with additional 49 pins than 1151 that allow for improved power efficiency and eventual updates with multiple I/O devices. However, this LGA 1200 isn’t compatible with the older generation CPU’s meaning that you won’t use the Comet Lake and Rocket Lake Desktop CPUs on the older LGA Sockets. Like the LGA 1151, it has four heatsink holes allowing for the same cooling as the older 1150 and 1151 Intel LGA sockets.

LGA 1150 vs 1151 vs 1200

Here is a detailed comparison chart comparing all the specifications of the LGA 1150,1151 and 1120 Intel CPU sockets.

CPU SocketPinsOverclockingMemory SupportUSB ConnectionsVoltage SupportCompatibilityBackward Compatibility
LGA 11501150YesDDR33.0Supports only Low VoltageCompatible with Haswell & Broadwell processorsYes
LGA 11511151NoDDR3 + DDR42.0 and 3.0Supports both high and low voltagesCompatible With Skylake & Kaby Lake Desktop CPU’sNo
LGA  12001200 YesDDR42.0 and 3.0Supports both high and low voltagesCompatible with Comet Lake & Rocket CPUsNo

1. Number Of Pins

The LGA 1150 H3 CPU Socket has 1150 pins on the motherboard to facilitate communication between the motherboard and the processor. The LGA 1151 has 1151 pins on the bottom of the socket that facilitate communication between the processor and the motherboard. 1200 comprises 1200 pins mounted at the rear of the motherboard that facilitates communication between the motherboard and the processor. It comes with 49 additional pins than the 1151 that allow for improved power efficiency and eventual updates with multiple I/O devices.

2. Compatibility

The LGA1150 is compatible with Intel B85, H81, H87, Q85, Q87, Z87, H97, Z97 desktop chipsets and Intel C226 server chipset. However, it is NOT compatible with the Skylake processor.

The LGA 1150 H3 socket is compatible with Haswell and Broadwell processors. The LGA 1151 H4 Socket is compatible with Intel’s Skylake And Kaby Lake Desktop CPUs. The LGA 1200 is a modified version of the 1151 socket and is consistent with the Comet Lake and Rocket Lake Desktop CPUs. However, processors based on LGA 1151 and LGA 1200 CPU sockets are electrically incompatible. The 1151 CPU socket supports both 8th and 9th generation CPUs that use the Intel 300 chipset, such as the H310, B360, Z370, and Z390. Meanwhile, the Intel LGA 1200 CPU socket is only compatible with 10th generation Intel Core processors (You can check the in-depth reviews of motherboards compatible with Intel i3 10100, i5 10600K, i7 10700K and i9 10900K)

3. Memory Support

The LGA 1150 H3 socket is fully compatible with DDR3 RAM. However, the LGA 1150 is not compatible with DDR4 memory. Meanwhile, the LGA 1151 H4 socket supports both DDR4 and DDR3 RAM. The LGA 1200 Intel CPU socket supports only DDR4 RAM. Meanwhile, the 1200 LGA sockets support variety of techs such as HEVC, HDR, VGI, and VP9 10-bit encoding.

4. Heatsink

The 1151 CPU socket uses the right orientation with the heatsink fastening holes placed in a square formation. Similar to the LGA 1151, the 1200 LGA Intel CPU socket has four heatsink holes allowing for the same cooling as the older 1150 and 1151 Intel LGA sockets.

5. Overclocking

Apart from the Intel 1151 LGA CPU Socket, both the 1150 and 1200 allow overclocking.

Conclusion

We hope our article was able to walk you through everything there is to know about the Intel LGA 1150,1151 and the 1200 CPU sockets. Our entire computing setup revolves around how strong is our motherboard. Be it for hardcore gaming or routine office work, we all want a smooth, fast, and efficient design. This is where knowledge about motherboards, processors, and CPU sockets comes in handy. The CPU socket embedded in your motherboard indicates the CPU generation and the components it is compatible with.
